2244L 21.5" Open Frame Touchscreen (Discontinued August 2013)
Comment acheter

Overview

The Elo Touch Solutions 2244L open-frame LCD touchmonitor with its slim design and narrow outside dimensions gives kiosk integrators an edge in developing the most aesthetically pleasing products. Wide-aspect displays like the Elo 2244L are easier to use and incorporate than traditional open-frame touchmonitors. Wide-screen format displays allow extra content on the screen and are quickly becoming preferred in casino gaming, amusement and entertainment settings and are increasingly popular in public venue environments due to the high-definition cinematic-like experience. Typical applications for the 2244L include: gaming and amusement, information kiosks and self-service, as well as interactive digital signage applications.

State-of-the-art LED backlighting used in the 2244L makes the panel thinner overall as the cold cathode fluorescent lights (CCFL) are replaced with LED lights. LED lights also take less electricity to operate and generate less heat. This leads to the slimmer dimensions of the 2244L that facilitate OEMs and system integrators the flexibility to design aesthetically pleasing and stylish kiosks.

Available with IntelliTouch, IntelliTouch Plus, standard bezel surface acoustic wave, as well as IntelliTouch Zero-Bezel SAW and IntelliTouch Pro projected capacitive touchscreen technology for a true flat look,, the 2244L provides stable "drift-free" operation with outstanding image clarity, resolution, and light transmission - for an accurate touch response and vivid images. Projected capacitive provides a durable, zero-bezel, glass-to-edge surface with multi-touch, while surface acoustic wave is the optical standard of touch and widely used in kiosk and gaming applications. Both are pure glass constructions to deliver a clear, bright and long-lasting performance and it also makes the touchscreens scratch-resistant. It is nearly impossible to physically "wear out" these touchscreens.

Features

  • Slimmer dimensions enables thinner, artistic enclosure designs
  • Multi-touch, dual-touch and single touch options available
  • High definition LCD display offers ultimate HD interactivity, clarity and resolution
  • Portrait and landscape mode possible
  • IntelliTouch Pro projected capacitive passes ball-drop impact testing to IK07 and UL 60950 standards and offers four touch points (HID)
  • Viewing angle of 178°(h) × 178°(v), wider than most 22” touchmonitors, allows colors to remain sharp and graphics to retain their integrity in both portrait and landscape modes
  • 16:9 aspect ratio and bright 250 nits panel for a larger display surface and bright vivid images
  • LED backlighting allows for state-of-the-art slim design while reducing power consumption
  • Optimized for use in high-traffic environments
  • Three year warranty

Spécifications

  • Technique

    Référence(s)

    APR (Antiglare, Worldwide) - E738068

    Couleur du boîtier

    Noir

    Technologie et fonctionnalités tactiles

    Reconnaissance d'impulsion acoustique - Touche unique

    Interface tactile

    USB

    Taille de l’écran (diagonale)

    Diagonale de 21.5”, matrice active TFT LCD (LED)

    Affichage à l’écran (OSD)

    Controls: Menu, Up, Down, Select
    Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, OSD H-Position, OSD V-Position, Recall Defaults, Video Source
    Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese
    Lockouts: OSD, Power

    Accessible through switches on the unit's tethered OSD Control Box.

    Format d’image

    16:9

    Zone active

    18.7" x 10.5" / 475 mm x 267 mm

    Résolution

    1920x1080

    Autres résolutions prises en charge

    640x480 60Hz
    720x576 50Hz
    800x600 56, 60Hz
    1024x768 60Hz
    1280x720 50, 0Hz
    1280x960 60Hz
    1280x1024 60Hz
    1366x768 60Hz
    1440x900 60Hz
    1680x1050 60Hz
    1920x1080 50, 60Hz

    Angle de vision

    Horizontal: ±89° ou 178° au total / Vertical: ±89° ou 178° au total

    Nombre de couleurs

    16.7 millions

    Luminosité (standard)

    LCD panel: 250 nits

    Temps de réponse – total (standard)

    14 msec

    Taux de contraste

    1000:1

    Format vidéo d’entrée

    Analog VGA, DVI-D

    Connecteur du signal vidéo d’entrée

    Analog VGA on Female DE-15 connector; Digital on Female DVI-D connector

    Alimentation électrique

    External DC - Optional power brick (sold separately)

    Connecteur d’entrée d’alimentation (écran)

    Type: DC Barrel Jack
    Barrel inner diameter: 6.4mm (+/- 0.3mm)
    Pin outer diameter: 2.0mm (+0.0 -0.1mm)
    Input voltage range: +12VDC ±5%

    Connecteur d’alimentation (bloc d’alimentation)

    Type: IEC 60320 C14
    Adapter input voltage range: 100-240VAC, 50/60Hz

    Tension d’entrée

    +12VDC ±5%

    Connecteur d’entrée

    DC Barrel Jack

    Fréquence d’entrée

    Horizontal: 31.5-80 kHz
    Vertical: 50-75 Hz

    Consommation électrique (standard)

    ON (monitor only): 26W
    ON (monitor + AC/DC adapter at 230V/50Hz): 39W
    SLEEP (monitor + AC/DC adapter at 230V/50Hz): 1.5W
    OFF (monitor + AC/DC adapter at 230V/50Hz): 1.0W

    Dimensions

    Please reference the dimensional drawing

    Dimensions du colis d’expédition

    7.87" x 16.93" x 24.41" / 200 mm x 430 mm x 620 mm

    Poids (non emballé)

    10.6 lbs / 4.8 kg

    Poids (emballé)

    15.3 lbs / 7.0 kg

    Température de fonctionnement

    0°C to 40°C / 32°F to 104°F

    Température de stockage

    -20°C to 60°C / -4°F to 140°F

    Humidité

    Operating: 20%-80% Storage: 10%-90%

    Temps moyen entre défaillances

    50 000 heures démontrées

    Garantie

    3 ans

    Homologations et déclarations

    S-Mark, C-Tick, cUL, IC, CCC, CE, VCCI, KCC, Mexico CoC, Taiwan BSMI, UL, FCC, International CB
    RoHS, China RoHS, WEEE, IMERC

    Options de montage

    VESA 4-hole 100mm mounting interface on rear of unit
    2-hole mounting interface on all 4 sides

    See dimensional drawings for details

    Options/Périphériques/Mises à jour

    Télécommande OSD (RJ45): E483757
    Kit de câble de remplacement: E378229
    Adaptateur électrique et kit de câbles pour l'Amérique du Nord: E005277
    Adaptateur électrique et kit de câbles pour l'Europe et Corée: E571601
    Adaptateur électrique et kit de câbles pour le Royaume-Uni: E180092
    Adaptateur électrique et kit de câbles pour la Chine: E558862
    Adaptateur électrique et kit de câbles pour Taïwan: E818655
    Adaptateur électrique et kit de câbles pour le Japon: E182546
    Adaptateur électrique et kit de câbles pour l'Argentine: E887099
    Stylet IntelliTouch: D82064-000
    Elo 22 pouces - Support de montage sur étagère: E462672
    Elo 22 pouces - Cadre large de fixation avant: E668194
    Elo 22 pouces - Supportlarge de montage en L: E530432

    Stylet IntelliTouch en option

    Stylus pen with rubber tip, designed specifically for use with IntelliTouch surface wave touch technology. Part number D82064-000, available at additional cost
